CATALOG
3 THE MARVIN PORTFOLIO The Marvin portfolio consists of five product lines organized into three distinct collections defined by the degree of design detail and customization opportunities. Marvin windows and doors offer exceptional performance, energy efficiency, low maintenance, and quality you can see, feel, and touch to help bring your vision to life. ULTIMATE Most extensive selection of features, options, and product types MODERN Design flexibility in a purely modern aesthetic available exclusively at Marvin Modern dealers COASTLINE Custom windows and doors for high velocity hurricane zones in the coastal Southeast ELEVATE Wide range of options and product types ESSENTIAL Curated options and product types MARVIN SIGNATURE® COLLECTION MARVIN ELEVATE® COLLECTION MARVIN ESSENTIALTM COLLECTION INTERIORS WOOD 6 species options + custom 2 painted or primed options 6 stains + clear coat EXTRUDED ALUMINUM 5 color options EXTRUDED ALUMINUM 6 solid colors, 4 woodgrain finishes WOOD Bare pine, painted Designer Black, painted White, or clear coat FIBERGLASS 4 color options EXTERIORS EXTRUDED ALUMINUM 19 colors + custom OR WOOD 3 species + custom FIBERGLASS 5 color options EXTRUDED ALUMINUM 6 solid colors, 4 woodgrain finishes FIBERGLASS 6 color options FIBERGLASS 6 color options SIZING Standard + custom sizing for replacement, remodeling, or new construction Custom sizing for remodeling or new construction Custom sizing for replacement, remodeling, or new construction Standard + custom sizing for replacement, remodeling, or new construction Standard + custom sizing for replacement, remodeling, or new construction HARDWARE Extensive selection including Marvin Gallery Hardware Minimalist hardware for modern design aesthetic Available in multiple styles, sizes, and finishes to complement the window + door aesthetics Available in 6 finish options with 2 door handle styles Available in 6 finish options with 1 door handle style COASTAL + WATERFRONT Hurricane Impact Zones 3 and 4, + PG 50 Products All products rated for High Velocity Hurricane Zone (IZ4) Hurricane Impact Zone 3, + PG 50 Products 2 MARVIN®
About Us At Marvin, we’re driven to imagine and create better ways of living, helping people feel happier and healthier inside their homes. We believe that our work isn’t just about designing better windows and doors—it’s about opening new possibilities for the people who use them. Marvin Essential collection DESIGN AND PERFORMANCE MADE EASIER Characterized by clean lines, powerful performance, and streamlined options, the Marvin Essential collection makes it easier to achieve design and quality. The Essential collection features durable Ultrex® fiberglass interiors and exteriors, making it virtually maintenance free. 4 MARVIN ESSENTIALTM COLLECTION 5 MARVIN® Casement, Picture, and Awning windows in Ebony
TABLE OF CONTENTS 5 MARVIN ESSENTIAL COLLECTION 8 WHY MATERIALS MATTER 10 ENERGY EFFICIENCY 12 DESIGNED WITH PROS IN MIND 14 WINDOWS + DOORS 16 CASEMENT + AWNING 18 SINGLE HUNG 20 DOUBLE HUNG 22 GLIDER 24 PICTURE 26 ROUND TOP + SPECIALTY SHAPES 28 SLIDING PATIO DOOR 30 PRODUCT OPTIONS 32 INSTALLATION ACCESSORIES 33 EXTERIOR TRIM 34 DESIGN OPTIONS 36 HARDWARE STYLES 7 MARVIN® 6 MARVIN ESSENTIALTM COLLECTION Direct Glaze windows in Ebony
WHY MATERIALS MATTER THE MARVIN MATERIALS DIFFERENCE: ULTREX® FIBERGLASS Choosing the right materials for windows and doors is important when it comes to long-term appearance and performance. Ultrex, an innovative fiberglass material pioneered by Marvin over 25 years ago, was one of the first premium composites on the market. However, not all composites are created equal. Some companies use materials with fundamentally different properties and performance values to produce a composite material. Ultrex is different. High-density woven fibers bound by a thermally set resin makes Ultrex more resistant to pressure and temperature than vinyl-based composites. With such different materials grouped in the composites category, it is essential to know what sets them apart. STRENGTH AND STABILITY OF ULTREX Ultrex pultruded fiberglass has a tensile strength 8x stronger than vinyl and 3x stronger than non-fiberglass vinyl/wood composites. Windows and doors made with Ultrex bend and flex less, resist cracking and separating, and stand up better to everyday wear and tear. The exceptional strength and stability of Ultrex eases installation and establishes a secure, long-lasting fit that stays square and true year after year. PULTRUDED FIBERGLASS Thin strands of strong glass cables saturated with compounded resins create a durable material. DURABLE FINISH The proprietary finishing process applies a durable, long-lasting AAMA 624 verified factory finish. ULTREX COMPOSITES COMPOSITES ULTREX ACRYLIC CAP VINYL/WOOD COMPOSITE (FIBREX®) GLASS ULTREX ALUMINUM VINYL .6 .4 1.3 1.6 4.0 0 .5 1.5 1.0 2.0 2.5 3.0 3.5 4.0 x10-5 in/in/F – ASTM D696 TEMPERATURES MAY FLUCTUATE, BUT ULTREX® FIBERGLASS WON’T Ultrex expands and contracts at virtually the same rate as glass, so it works with glass rather than against it. This means seals aren’t as prone to leaking, and windows aren’t subjected to sagging issues like other composites. This is especially true when compared to vinyl, which can distort in extreme heat and crack in fluctuating temperatures. Ultrex resists distortion even at temperatures up to 285°F. Rapid temperature change doesn’t phase Ultrex. From -30°F to 70°F, a 6-foot stile changes less than 1/32 inch in length. EXPANSION MEASUREMENT Ultrex expands and contracts at virtually the same rate as glass. INDUSTRY’S BEST FIBERGLASS FINISH FOR LASTING BEAUTY Ultrex is the first and only fiberglass finish to be verified to AAMA’s 624 voluntary finish specifications for fiber-reinforced thermoset profiles (fiberglass). Windows and doors made with Ultrex resist scratches, dings, and marring more than vinyl. Our proprietary, mechanically bonded acrylic finish is up to three times thicker than painted competitive finishes, and it resists UV degradation up to five times longer than vinyl—even on dark colors. Double Hung windows in Stone White 9 8 MARVIN ESSENTIALTM COLLECTION MARVIN®
* ENERGY STAR® at energystar.gov COOLER IN SUMMER, WARMER IN WINTER TOP RATED ENERGY EFFICIENCY The National Fenestration Rating Council (NFRC) defines energy performance ratings for the entire window and door industry. It rates: • U-factor: How well a window keeps heat inside a building. • Solar heat gain: A window’s ability to block warming caused by sunlight. • Visible light transmittance: How much light gets through a product. • Air leakage: Heat loss and gain by air infiltration through cracks in the window assembly. Ultrex® fiberglass is 500 times less conductive than roll-form aluminum, similar to wood and PVC. It provides an insulated barrier against extreme weather temperatures, keeping homes comfortable and reducing heating and cooling costs. ENERGY COST SAVINGS Marvin was the first major window and door manufacturer to offer energy-efficient Low E2 glass and ENERGY STAR® certified performance on all of our standard windows and doors. Compared to noncertified products, ENERGY STAR certified windows and doors cut heating and cooling costs by 12%.* The Essential collection offers Low E1, Low E2, Low E3, and Low E3/ERS insulated glass with argon gas, which has thermal conductivity 30% lower than that of air. It adds improved solar and thermal protection by distinguishing between visible light, damaging UV, and near-infrared rays to offer the ultimate glass performance. In addition, it provides a selection of energy-efficient solutions depending on your climate and needs. LOW E GLASS COATING The Low E coating is specially designed to take advantage of the angle of the winter and summer sun. Winter sun is absorbed and conducted indoors. Summer sun is filtered and reflected back outdoors. ^ LOW E GLAZING WINTER SUN SUMMER SUN ^ LOW E GLAZING A MORE COMFORTABLE INTERIOR, REGARDLESS OF THE SEASON Keep heat inside during cooler weather and block the sun’s rays during warmer weather with dual-pane windows and Low E coating. Double Hung windows in Stone White 10 MARVIN ESSENTIALTM COLLECTION 11 MARVIN®
DESIGNED WITH PROS IN MIND PEACE OF MIND Every project has its own unique requirements, and Marvin is equipped to meet those challenges. Our unique Ultrex® fiberglass construction, available factory services, unmatched delivery, and network of dedicated service and support personnel make the Essential collection the perfect choice—no matter the project. EASY TO ORDER, SIMPLE TO INSTALL The Essential collection offers simplified options to make the order process straightforward. Installation options and accessories make installing Marvin easier than ever. See page 18 for more information. MARVIN HAS YOU COVERED The Essential collection is backed by a fully transferable 20/10 warranty—20-year coverage on glass, and 10-year coverage on manufacturing materials and workmanship. CREATING VALUE AND EFFICIENCY EVERY STEP OF THE WAY Weather-tight, solid, and durable Ultrex® fiberglass means there are virtually no call-backs. Essential window and door profiles are optimized for the maximum in performance and fit. Double Hung window in Stone White 12 MARVIN ESSENTIALTM COLLECTION 13 MARVIN®
Marvin Essential collection WINDOWS + DOORS Essential Casement and Direct Glaze windows in Ebony and Elevate Sliding French door in Designer Black 14 MARVIN ESSENTIALTM COLLECTION 15
CASEMENT + AWNING • Multi-point sequential locking system provides superior PG40 performance rating with single lever operation. • Stationary, operating, direct glaze rectangle and picture units available. • Folding handle provides easy operation and neatly stows out of the way of window treatments and blinds. • Casement available in standard and special sizes up to 3 feet wide by 7 feet high. • Awning available in standard and special sizes up to 5 feet wide by 4 feet high. • Coordinating Casement Picture window available up to 7 feet high and Casement Transom window available up to 6 feet wide by 2 feet high. • Features an easy to remove screen with concealed fasteners. • Crank out operation. CASEMENT + AWNING CASEMENT INTERIOR AWNING INTERIOR FOLDING HANDLE SHOWN IN OIL RUBBED BRONZE Awning and Picture windows in Ebony 16 MARVIN ESSENTIALTM COLLECTION 17 MARVIN® Casement windows in Ebony with Matte Black hardware
SINGLE HUNG • Features a fixed top sash and a movable bottom sash for a traditional double hung look. • Comes with a standard aluminum half screen; optional full screen is available. • Lower sash lock provides a positive detent, reassuring user that the window is either locked or unlocked. • Equal, Cottage, and Reverse Cottage sashes provide a variety of looks and checkrail heights. • Up to PG50 performance rating. • Factory, reinforced, and field-mulling kits available. • Standard and special sizes up to 4 feet wide by 6 feet 6 inches high. • Coordinating Picture and Transom windows available in sizes up to 5 feet wide by 6 feet high. • The lower sash removes easily with no strings or cords to detach. SINGLE HUNG INTERIOR EXTERIOR COTTAGE AND REVERSE COTTAGE SASH RATIO Single Hung windows in Bronze Essential Single Hung windows in Stone White 19 MARVIN® 18 MARVIN ESSENTIALTM COLLECTION
DOUBLE HUNG • Two movable sashes with versatility to create ventilation at the top, bottom, or both. • Equipped with a standard full screen; optional half screen is available. • Tilt latches are ergonomically designed and easy to operate, making tilting and cleaning effortless. • Up to PG50 performance rating on a majority of sizes. • Equal, Cottage, and Reverse Cottage sashes provide a variety of looks and checkrail heights. • Factory, reinforced, and field-mulling kits available. • Available in standard and special sizes up to 4 feet wide by 6 feet 6 inches high. • Coordinating Picture and Direct Glaze Rectangle windows available in sizes up to 5 feet wide by 6 feet high. DOUBLE HUNG INTERIOR EXTERIOR TILT MODE FOR EASY CLEANING Double Hung windows in Stone White Double Hung windows in Stone White 21 MARVIN® 20 MARVIN ESSENTIALTM COLLECTION
GLIDER • Perfect alternative to a swinging sash. • Operating sash easily tilts and removes with no cords or strings to detach. • Tilt latches are ergonomically designed and easy to operate, making tilting and cleaning effortless. • Innovative screen design for easy installation and removal. • Triple-sash option provides the appearance of a Picture window assembly. • Available in dual-sash with left or right operating panel as well as triple-sash with fixed center panel and two operating end panels. • PG25 performance rating on triple-sash and up to PG40 performance rating on dual-sash. • Available in standard and special sizes up to 6 feet wide by 5 feet high for dual-sash and 8 feet wide by 5 feet high for triple-sash. GLIDER INTERIOR EXTERIOR GLIDER PULL SHOWN IN WHITE Glider window in Ebony Glider and Picture windows in Ebony 23 MARVIN® 22 MARVIN ESSENTIALTM COLLECTION
PICTURE • Fixed window available in either in-sash or direct glaze to meet various design needs. • Direct glaze: › Glass meets the frame directly without a sash for a simple, clean profile with more glass area. › Available in sizes up to 9 1/2 feet wide by 9 1/2 feet high, not to exceed 49 square feet. • In-sash: › Designed to match profiles of operable windows in the Essential collection. › Casement Picture window available in sizes up to 7 feet high › Double Hung Picture windows available in sizes up to 5 feet wide by 6 feet high. PICTURE INTERIOR EXTERIOR INTERIOR WINDOW PROFILE SHOWN IN STONE WHITE Picture windows in Ebony Picture windows in Ebony 25 MARVIN® 24 MARVIN ESSENTIALTM COLLECTION
ROUND TOP + SPECIALTY SHAPES TRUE HALF ABOVE SPRINGLINE HALF ROUND EYEBROW ABOVE SPRINGLINE • Constructed of a glass reinforced composite capped with proprietary acrylic finish. • Complements Ultrex® fiberglass performance and radius profile. • Available nailing fin, installation bracket, and through jamb installation. • Perforated folding radius nailing fin provides for simple installation and proper water management. • Available factory and field-mulling options. • Standard and special sizes up to 8 feet wide and up to 7 feet high depending on the shape. • Up to PG50 performance rating. ROUND TOP EXTERIOR + INTERIOR ISOSCELES TRIANGLE OCTAGON TRAPEZOID (R & L) PENTAGON RECTANGLE 90˚ TRIANGLE (R & L) • Jambs are available factory applied or in an extension kit in 4 9/16 inch and 6 9/16 inch sizes. • Consistent, fast delivery applies to even the most unique products. • PG50 performance rating. • Factory, reinforced, and field-mulling kits available. • Available in sizes up to 49 square feet. Longest leg may not exceed 9 1/2 feet. SPECIALTY SHAPES INTERIOR PENTAGON INTERIOR ISOSCELES TRIANGLE Round Top and Direct Glaze windows 26 MARVIN ESSENTIALTM COLLECTION 27 MARVIN®
SLIDING PATIO DOOR • A top hung sliding screen operates smoothly without jamming. • Matching handle set design provides style and security. • Optional slim handle provides 32-inch net clear opening on certain 2- and 3-panel configurations (see page 36). • Up to PG30 performance rating. • Doors come with standard tempered Low E2 insulated glass with argon gas. Optional Low E1, Low E3, and Low E3/ERS meet diverse energy-efficiency needs. • Available in standard and special sizes up to 8 feet wide by 8 feet high for 2-panel configurations, and 9 feet wide by 8 feet high for 3-panel configurations. • Coordinating Direct Glaze Rectangle windows available. SLIDING PATIO DOOR INTERIOR EXTERIOR SILL DETAIL SHOWN IN BRONZE Sliding Patio Door in Bronze with Matte Black handle Sliding Patio door in Ebony with Matte Black hardware Essential Sliding Patio Door in Stone White with White Cambridge handle 29 MARVIN® 28 MARVIN ESSENTIALTM COLLECTION
Marvin Essential collection PRODUCT OPTIONS Casement and Direct Glaze windows in Ebony 30 MARVIN ESSENTIALTM COLLECTION 31 MARVIN®
INSTALLATION MADE SIMPLE AND EFFICIENT NAILING FIN Snaps out for easy installation. JAMB EXTENSION Allows for easy finishing with traditional molding and trim. J-CHANNEL Quickly and easily finishes the exterior. SHEETROCK RETURN Accommodates 1/2"–5/8" drywall installations. 3/4" RECEIVER Works with thicker installation methods, including box jambs. FRAME EXPANDER Provides installation flexibility. GLIDER WOCD Limits opening to 4" while providing for full egress. ASTM F2090-10 compliant. DOUBLE/SINGLE HUNG SASH LIMITER Permanently limits sash movement for safety and security. CASEMENT WOCD Limits opening to 4" while providing for full egress. ASTM F2090-10 compliant. NON-OPERABLE LOCK Renders sash inoperable. DOUBLE/SINGLE HUNG WOCD Limits opening to 4" while providing for full egress. ASTM F2090-10 compliant. CASEMENT/AWNING 3" SASH LIMITER Permanently limits sash movement for safety and security. Marvin Essential windows and doors bring together design, quality, and performance in one streamlined collection. Essential products offer a number of installation options and accessories that make it easy to meet project demands. TRIM CONFIGURATIONS Multiple configurations are available in lineal lengths and factory pre-cut kits in all six Essential collection exterior colors. BRICK MOULD BRICK MOULD WITH SILL NOSE FLAT FLAT WITH SILL NOSE FLAT RANCH FLAT RANCH WITH SILL NOSE BRICK MOULD* FLAT* FLAT RANCH* * Brick Mould, Flat, and Flat Ranch profiles are available on doors. Sill profiles are not included for door trim sets. EXTERIOR TRIM Ultrex® Exterior Trim is offered with all rectangular Marvin Essential products in six exterior finishes. The durability, performance, and look of Essential collection windows and doors can be extended to the trim. BRICK MOULD 2" Brick Mould is available with or without 2 1/8" sill nosing. FLAT 3 1/2" Flat Trim is available in Flat and Flat Ranch configurations with or without 2 1/8" sill nosing. SILL NOSE 2 1/8" Sill Nose provides authentic sill appearance. CONNECTION BARB Barb and receiver attachment method provides for quick, secure installation. BRICK MOULD SILL NOSE FLAT CONNECTION BARB 32 MARVIN ESSENTIALTM COLLECTION 33 MARVIN®
INTERIOR AND EXTERIOR FINISHES Essential windows and doors have a durable, strong, and fully paintable Ultrex® fiberglass interior and exterior, featuring our AAMA-verified acrylic finish for low-maintenance and superior aesthetics. DIVIDED LITES GRILLES-BETWEEN-THE-GLASS (GBG) Available in several popular lite cut options for a classic divided lite look and easy glass cleaning. Available in Stone White, Bronze, Gunmetal, or Ebony interior finish and Stone White, Cashmere, Pebble Gray, Bronze, Gunmetal, or Ebony exterior finish.* DESIGN OPTIONS * Not available in polygons except direct glaze rectangles. GRILLES-BETWEEN-THE-GLASS SHOWN IN STONE WHITE FIBERGLASS EXTERIOR COLORS DECORATIVE GLASS OBSCURE GLUE CHIP BRONZE TINT FROST RAIN GRAY TINT REED GREEN TINT NARROW REED GLASS OPTIONS Available in dual-pane in Low E1, Low E2, Low E3, and Low E3/ERS insulated glass with argon gas.* Options include glazing for sound abatement (STC/OITC), high altitudes, and California fire zones. * Argon gas not available in high elevations where capillary tubes are required. EBONY STONE WHITE CASHMERE PEBBLE GRAY BRONZE GUNMETAL Casement window with Low E2 glass FIBERGLASS INTERIOR COLORS STONE WHITE Available with your choice of exterior finish colors EBONY Available when paired with Ebony exterior finish BRONZE Available when paired with Bronze exterior finish GUNMETAL Available when paired with Gunmetal exterior finish 34 MARVIN ESSENTIALTM COLLECTION 35 MARVIN®
FOLDING HANDLE Casement and Awning HARDWARE STYLES WINDOW HARDWARE Windows feature classic low-profile, durable hardware for clean aesthetics, safety, and security. SASH LOCK + KEEPER Double Hung, Single Hung, and Glider DOOR HANDLE Sliding Patio Doors feature classic profile durable hardware, a perfect blend of safety and security. DOOR HANDLE OPTIONS • Available keyed-alike option (use one key on multiple locks with up to 3 different keys on each project). • Choose a distinct interior and exterior handle finish that matches or complements the interior and exterior color of your door. FINISHES Choose from a variety of hardware finishes to complement your Essential collection windows and doors. The Physical Vapor Deposition (PVD) process adds a layer of toughness to hardware exposed to environmental factors like direct sun and humidity. PVD finishes resist fading and discoloration, even in coastal areas. PVD has the highest grade corrosion resistant finish. PVD finish is available on exterior door hardware in Oil Rubbed Bronze, Satin Nickel, and Brass. Double Hung window with Sash Lock and Sash Lift in Oil Rubbed Bronze OIL RUBBED BRONZE (PVD) ALMOND FROST SATIN NICKEL (PVD) BRASS (PVD) WHITE MATTE BLACK Essential Direct Glaze windows in Ebony and Ultimate Sliding Patio door in Designer Black Sliding Patio door with Cambridge hardware in Satin Nickel CAMBRIDGE SLIM LINE EXTERIOR HANDLE 36 MARVIN ESSENTIALTM COLLECTION 37
THE MARVIN ESSENTIAL COLLECTION BRINGS TOGETHER DESIGN, QUALITY, AND PERFORMANCE IN ONE STREAMLINED OFFERING. Strong, durable Ultrex® fiberglass exteriors and interiors are both striking and virtually maintenance free. Simplified options make the order process straightforward, while clean lines and versatile styles make it easy to meet project demands. Direct Glaze windows in Ebony 39 MARVIN® 38 MARVIN ESSENTIALTM COLLECTION
©2024 Marvin Lumber and Cedar Co., LLC. All rights reserved. ®Registered trademark of Marvin Lumber and Cedar Co., LLC. ENERGY STAR® and the ENERGY STAR certification mark are registered US marks. Cover Image: Essential Casement, Specialty Shapes, and Direct Glaze windows Part #19981901. June 2024. [MUT] Colors shown in printed materials are simulations and may not precisely duplicate product or finish colors. Contact your local Marvin dealer to view actual product and finish color samples. Since 1912, Marvin has been a family-owned and -led company, with a legacy of innovation and commitment to the highest quality. We understand the unique opportunity windows and doors have to improve our spaces and how we feel in them. That’s why we never stop pushing what’s possible and inventing new solutions to channel fresh air, enhance light quality, and connect with the world around us. MARVIN.COM
