EccoDoors.com STILE & RAIL DOORS ROUTER CARVED DOORS
A CUT ABOVE THE REST 2 All stile & rail and router carved doors are manufactured in our factory located in Boynton Beach Florida. There is no limitation to the number of designs we offer, we can accommodate almost any custom design you may require. (3226) 1-866-992-ECCO Call us toll free if you need help with a door design, standard or custom built.
3 TABLE OF CONTENTS EccoDoors.com Router Carved ER4000 4-5.. . . . Shaker Series (Stile & Rail) 6...... Classic Collection : Sticking & Panel Options 7...... Classic Collection : Molding Options 8-9 . . . . Classic Collection 10-11 . . . Italia Range 12-15 . . . Router Carved Doors 16 . . . . . Stain Grade : Sticking & Panel Options 17 . . . . . Stain Grade Doors 18 . . . . . Louver Doors 19 . . . . . Glass Doors/Pocket Doors/Barn Doors 20-21 . . . Fire Doors 22..... Pre Hung Doors & Jambs 23..... High Rise & Hospitality
SHAKER SERIES Stile and Rail ES1000 C Sticking + F Panel ES5000 C Sticking + F Panel ES3000 C Sticking + F Panel with Amalfi Molding ES2110 B Sticking + F Panel with Cascade Molding Amalfi Molding Cascade Molding Milano Molding Trifecta Molding Florentina Molding Ecco Shaker Series doors are constructed with the correct thickness panels to provide a stylish contemporary look that fits easily into any environment. Most other manufacturers skimp on the panel thickness which results in a flimsy door. We offer a full range of standard sizes, and can tailor make your door to your exact dimensions if required. We also offer the Shaker doors with an added top wooden edge which can be used in pocket door and barn door applications. 4 EccoDoors.com Molding Options
Type B Sticking C – Skaker Type Sticking Type C Sticking Section MDF Section Stave Core Solid MDF Wood Edge MDF Face Stave Core 5 Solid MDF Wood Edge ES1000 ES2000 ES4000 ES5000 ES3000 ES2000L ES2070 ES2110 ES3080 ES2100 ES3090 ES3100 ES3120 ES3130 ES3110 ES4040 ES4050 ES3140 ES4010 ES4030 ES5020 ES5030 ES6010 ES6000
CLASSIC COLLECTION Stile and Rail 6 STICKING OPTIONS A – Standard Sticking B – Type B Sticking C – Skaker Type Sticking D – Wedge Type Sticking E – Oval ‘O’ Sticking T – Type T Sticking A – Standard Panel D – Double Hip Panel S – ScoopPanel F – Flat Panel M – Type M Panel With our Classic Collection you have the choice of numerous sticking, panel and molding options that allow you to customize the door to suit your decorating needs. You can combine all the elements and virtually design your own door. We will be pleased to provide you with shop drawings of the door you have chosen so you can see exactly how it will look when it has been manufactured. PANEL OPTIONS EccoDoors.com
7 The timeless Classic Collection allows for the addition of raised moldings to enhance the depth and style of these doors. Listed on this page are the various raised molding options that are applicable to this collection. HL – Highline Raised Molding HB – Heavy Bolection Molding HL-PKT — HL Pocket Molding (Sunken) HM – Heavy Molding MOLDING OPTIONS CLASSIC COLLECTION Stile and Rail
E1000H E2000H E2000LH E2070H E2100H E2110H E3000H E3080H E3090H CLASSIC COLLECTION Stile and Rail 8 This collection of raised panel doors to which raised moldings can also be added, allows you to get a wide range of choices. These top quality doors are available in numerous standard sizes but can also be made to order to your size and specification. EccoDoors.com E2110H with Type ‘E’ Sticking and Type ‘S’ Panels
E4030H E4040H E4010H E4050H E4060H E5000H E5020H E5030H E6000H E6010H E6030H E6020H E3110H E3120H E3100H E3130H E3140H E4000H 9 The Classic Collection standard sizes: THICKNESS: 1-3/8” and 1-3/4” WIDTH: 18”, 24”, 28”, 30”, 32”, 34” and 36” LENGTH: 6’8”, 7’0” and 8’0” Custom sizes are available by special order. CLASSIC COLLECTION Stile and Rail
ITALIA RANGE Contemporary Elegance, the Less Cluttered Modern Look 10 The Italia Range is available in numerous configurations with any amount of horizontal, vertical, diagonal or random lines making up the door design. These modern and understated doors compliment any decorating style and are available in numerous standard sizes – custom sizes can also be made to order. The widths of the grooves and steps can be customized if needed. Send us your own design and we will do our best to make it for you. Diagonal Herringbone Diamond Newport Oxford EI2H EI2V EI3H EI2V EI2H EI2H EI2V EI3H EccoDoors.com
11 Signature Cosmopolitan COMO EI1000-50 Groove can be from ½” wide to 1” wide I2H EI4H EI3H EI2H2V EI5H EI3HM EI3H EI4H EI5H EI2H2V EI3HM EI2H EI4H EI3H EI2H2V EI5H EI3HM Section Thru Groove The Italia Range standard sizes: THICKNESS: 1-3/8” and 1-3/4” WIDTH: 18”, 24”, 28”, 30”, 32”, 34” and 36” LENGTH: 6’8”, 7’0” and 8’0” Custom sizes are available by special order. ITALIA RANGE Contemporary Elegance, the Less Cluttered Modern Look
Lucca Portofino Genoa Lucca Section Portofino Section Genoa Section ROUTER CARVED 12 Contemporary EccoDoors.com Lucca
ER2050 ER8800 ER4000 ER5000 ER3600 13 Panel and Sticking Section 1 3/4" Door Panel and Sticking Section 1 3/8" Door ROUTER CARVED ER Range
ROUTER CARVED 14 ER Range ER1000 ER1010 ER1020 ER1030 ER2000 ER2010 ER2050 ER2060 ER2070 ER2080 ER2100 ER2110 ER2200 ER3000 ER3010 ER3020 ER3600 Panel and Sticking Section 1 3/4" Door Panel and Sticking Section 1 3/8" Door EccoDoors.com
ER3030 ER3040 ER3050 ER3060 ER3090 ER3100 ER3110 ER3120 ER4000 ER4010 ER4020 ER4030 ER5010 ER5030 ER6000 ER6010 ER3070 ER3080 ER3140 ER3500 ER4040 ER5000 ER8000 15 ROUTER CARVED ER Range
A – Standard Sticking B – Type B Sticking C – Skaker Type Sticking D – Wedge Type Sticking E – Oval ‘O’ Sticking T – Type T Sticking A – Standard Panel D – Double Hip Panel S – ScoopPanel F – Flat Panel M – Type M Panel STICKING OPTIONS PANEL OPTIONS Rubber bumpers keep panels securely in place while allowing them to float 16 STAIN GRADE Top Quality
E2000 Red Oak C Sticking + F Panel E2000 Red Oak B Sticking + Cascade Molding E1000 Mahagony E Sticking + F Panel E1000 Walnut E Sticking + F Panel E5000 Soft Maple O Sticking + S Panel E3000 Poplar with Amalfi Molding STAIN GRADE Top Quality We are pleased to offer all the stile and rail doors shown in this brochure manufactured with various lumber options such as Oak, Mahogany, Walnut, Poplar, American Cherry, Maple, Elm, Ash and Pine etc. If you do not see the lumber species that you require listed here, please ask and we will let you know if we can accommodate your requirements. 17 EccoDoors.com
Ladder Louver Full Louver EFL1000 True Louver False Louver EFL2000 EPL2000 EPL2000B Groovy Louver LOUVER 18 Ladder Louver EccoDoors.com
19 G1000 G2000 G3000 G4000 G5000 G1000 Acid Etched Frosted Glass Barn doors can be made in any size or panel configuration. Flush doors can be manufactured up to 60” wide by 96” tall. Paneled and Glass doors can be made in larger sizes, call for more details. GLASS Glass comes standard in 1/4” thickness with one of the following options: Clear Tempered, Tempered Frosted, White Laminated, or Mirror. Beveled glass is available by custom order. BARN POCKET Pocket doors are designed with one stile 1” larger than the other. The wider stile sits in the pocket so the visible part of the stile is equal to the stile on the other side. The top rail has an extra wood edge to accommodate hangers and fittings. The top rail can also be made 1” larger if required. 5" 6" 6" 8ı/₄" Extra Top Edge in Top Rail
FIRE RATED 20, 45, 60 and 90 Minute Fire Rated MDF Doors 20 Fire Rated Door Jambs are available in virtually any width to match the wall thickness. Positive or negative pressure veneered in any wood species to match doors with up to 90 minute ratings. 3/4" Intumescent Core Width of Wall All Fire Rated Doors are constructed with intumescent cores which give them their fire rating. The look and design of the door is not compromised by the fire rating. Fire Rated Doors are utilized in commercial applications and in single family residential buildings from the garage to the house. Almost any design is available as a Fire Rated Door with ratings up to 90 minutes. (20, 45, 60 and 90) EccoDoors.com
21 All fire doors are 1 3/4" thick All fire doors are positive pressure rated (CAT. A) Except 20 Minute which can be made Cat B. Stile and rail construction to match non rated door designs Routered door design to match routed doors Can be made with raised or flat panels Stile & Rail Construction Intumescent Edge Intumescent Core Fire Door Max. Max. Max. Rating Thinkness Width Single Width Pair Height 20 Min. Cat A 1 3/4" 4' 0" 8' 0" 8' 0" 45 Min. Cat A 1 3/4" 3' 6" 7' 0" 8' 0" 60 Min. Cat A 1 3/4" 3' 6" 7' 0" 8' 0" 90 Min. Cat A 1 3/4" 3' 6" N/A 8' 0" High Quality Fire Rated QUALITY DESIGN FIRE RATED 20, 45, 60 and 90 Minute Fire Rated MDF Doors
PRE-HUNG Doors and Door Jambs 22 All of our doors can be pre-hung or pre-machined for hinges and locks. We use primed solid Poplar jambs (3/4” & 1-1/16” thick) as our standard and Pine jambs (11/16” thick) as a lower cost alternative. Stain grade doors are hung on the same wood type as the door. All of our pre-hangs have square corner hinges as standard, and we supply heavy duty ball bearing hinges in all the standard finishes to add a high level of finish to the door. View of doors while standing outside Standard Jamb Thickness 3/4" & 1 ı/16" – we also offer custom thickness jambs Stop Left Hand Reverse (LHR) Left Hand (LH) Right Hand Reverse (RHR) Right Hand (RH) DOOR HANGING GUIDE A – Standard Stop C – Wide Stop 2 1/2” 1/2” 1 1/2” 1/2” EccoDoors.com
HIGH RISE AND HOSPITALITY 23 PERFECT FOR HIGH END COMMERCIAL APPLICATIONS Great for use in hotels, office buildings and luxury living projects. EccoDoors can be custom designed and manufactured to your exact requirements. We will gladly work with you to create the custom door of your choice. We are fully versed with the special requirements for large projects and are able to offer the following. • A full set of shop drawings for your approval. • The supply of a full set of sample doors for the project. • Machining of all doors for hinges, locks, ball catches, flush bolts, pivot closers, etc. • Palletizing of doors by floor and tagging of doors by unit number. • Pre-scheduled on time delivery. • Shipping to customers designated destination. • Quick & Responsive reaction to any changes that may be required.
EccoDoors.com 866-992-3226 toll free 561-721-6660 phone Ecco Doors Manufacturing LLC 505 Industrial Way Boynton Beach, Florida 33426 STILE & RAIL DOORS ROUTER CARVED DOORS
